Description
Input
-
Nominal voltage: 208/220/230/240 VAC
-
Wide range: 100–280 VAC
-
Frequency: 50/60 Hz (auto-detection)
-
Input PF: 0.99 | THDi: ≤5%
Batteries and Charger
-
External (cabinet): 240 Vdc bus (20 × 12 V)
-
Intelligent charger 10 A (adjustable) | Recharge ≈ 4 h to 90%
Output
-
Voltages: 220/230/240 VAC
-
Waveform: Pure sine wave | THD: ≤2% (linear loads) / ≤6% (non-linear loads)
-
Frequency: 50/60 Hz ±1%
-
Overload: 110% (30 min), 125% (10 min), >150% instantaneous
-
Efficiency: 94–95% (double conversion)
Bypass
-
Static + external maintenance
Communications
-
RS-232 / USB | SNMP and Modbus RTU/TCP (optional) | dry contacts
Environmental Conditions and Noise
-
Noise: ≤58 dB
-
Operating temperature: 0–40 °C
-
Relative humidity: 0–95% non-condensing
Standards
-
IEC/EN 62040-1/2, CE marked; suitable for healthcare environment according to IEC 60601-1 (installation)*
*The UPS is not a medical device; it complies with EMC/safety standards for use in healthcare facilities.
Mechanical (reference)
-
Dimensions: 550 × 800 × 1100 mm | Weight: 120–150 kg
